LM311P Generic 10pcs DIP‑8 Voltage Comparator IC – Precision Low‑Power

Description

Product Overview

The LM311P is a classic voltage comparator designed for reliable operation in demanding industrial environments. Packaged in a 10‑piece DIP‑8 tray, each unit measures 0.39 x 0.39 x 0.39 inches and weighs only 0.04 ounces, making it easy to integrate into dense PCB layouts. Manufactured by Generic, the LM311P offers high input impedance, fast response time, and low quiescent current, ensuring accurate voltage threshold detection while minimizing power consumption. Its open‑collector output stage provides flexibility for interfacing with a variety of load conditions, and the device operates over a wide supply voltage range, supporting both 5 V and 15 V systems. The comparator’s temperature range of –40 °C to 85 °C guarantees stable performance across typical industrial temperature variations. Detailed specifications, including input offset voltage, bias current, and propagation delay, are documented in the datasheet, allowing engineers to design precise control loops, level‑shifting circuits, and protective monitoring systems with confidence.

Usage

Designed for signal conditioning, the LM311P excels in applications such as sensor interface circuits, power‑management modules, and automation control panels. Its low‑power operation makes it suitable for battery‑powered devices, while the fast switching capability supports high‑frequency PWM generation and pulse‑width modulation schemes. Typical usage scenarios include temperature sensor threshold detection, over‑voltage and under‑voltage protection, and comparator‑based oscillators for timing functions. The DIP‑8 form factor simplifies prototyping and mass production, allowing designers to quickly populate boards using standard through‑hole assembly processes. The device’s robust electrical characteristics also make it a reliable choice for automotive diagnostics, industrial motor control, and renewable energy inverter monitoring, where precise voltage comparison is essential for safe and efficient operation.

Why Choose Us

Choosing the Generic LM311P means selecting a component backed by rigorous quality assurance and consistent manufacturing standards. Each batch undergoes comprehensive testing to verify electrical performance, ensuring that every comparator meets the specified parameters for offset voltage, hysteresis, and output drive capability. Our supply chain guarantees traceability from raw material sourcing to final packaging, providing confidence in long‑term availability for production runs. In addition, we offer responsive technical support, detailed datasheets, and application notes to assist engineers throughout the design, testing, and deployment phases. With competitive pricing and reliable delivery schedules, the LM311P delivers both cost‑effectiveness and performance, making it an optimal choice for OEMs and system integrators seeking dependable signal processing components.

Key Features

• High‑precision voltage comparison with low offset for accurate threshold detection
• Low quiescent current reduces overall system power consumption
• Open‑collector output provides flexible interfacing with various load types
• Robust DIP‑8 packaging simplifies assembly and supports high‑volume manufacturing
• Dedicated technical support and comprehensive documentation for seamless integration

FAQ

What is the recommended supply voltage range for the LM311P?

The LM311P operates reliably with a supply voltage between 5 V and 15 V, allowing it to be used in both low‑voltage logic circuits and higher‑voltage industrial applications.

Can the LM311P be used for temperature sensor threshold detection?

Yes, the comparator’s high input impedance and precise voltage threshold make it well‑suited for monitoring temperature sensor outputs and triggering alerts when predefined limits are crossed.

How does the open‑collector output benefit my circuit design?

The open‑collector output can be pulled up to any voltage within the supply range, enabling you to drive higher‑voltage loads, interface with different logic families, or implement wired‑OR configurations without additional components.

Is the LM311P suitable for battery‑powered applications?

Its low quiescent current and efficient design make the LM311P an excellent choice for battery‑operated devices where power conservation is critical.

What support resources are available for integrating the LM311P?

We provide detailed datasheets, application notes, reference schematics, and a responsive engineering support team to assist with design questions, layout optimization, and troubleshooting.
